| Model | YHZS25 | YHZS35 | YHZS50 | YHZS75 | YHZS100 | |
|---|---|---|---|---|---|---|
| Theoretical Production (m³/h) | 25 | 35 | 50 | 75 | 100 | |
| Mixer | JS500 | JS750 | JS1000 | JS1500 | Js2000 | |
| Aggregate Maximum Particle(mm) | 60/40 | 60/40 | 80/60 | 80/60 | 80/60 | |
| Feeding Capacity (L) | 750 | 1150 | 1500 | 2250 | 3000 | |
| Discharge Capacity(L) | 500 | 750 | 1000 | 1500 | 2000 | |
| Aggregate Bin Capacity (m³) | 2x3 | 2x3 | 2x3 | 4x5 | 4x5 | |
| Aggregate conveyor belt | 800 | 1200 | 1200 | 2400 | 3200 | |
| Belt conveying Capacity (t/h) | 300 | 300 | 200 | 600 | 600 | |
| Screw conveyor Capacity(t/h) | 40 | 40 | 40 | 40-70 | 40-70 | |
| Breaking bucket capacity(m³) | 4.0 | 4.0 | 4.0 | 4.0 | 4.2 | |
| Installed capacity (kw) | 67 | 79 | 56 | 120 | 170 | |
| Weighing range | Aggregate | 200~800 ±2% | 250~1200 ±2% | 250~1200 ±2% | (600~ 2000)±2% | (700~2400)±2% |
| Cement | 70~350 ±1% | 100~500 ±1% | 100~500 ±1% | (200~800)±1% | (350~1200)±1% | |
| Water | 50~200 ±1% | 50~200 ±1% | Flow meter | (100~400)±1% | (150~550)±1% | |
| Additive | 10~30 ±1% | 10~30 ±1% | Flow meter | (6~30)±1% | (10~50%) ±1% | |
